Product Specifications
| Frequency | 50HZ/60HZ | Rated Voltage | 120, 220, 230, 120/240, 220/380 |
|---|---|---|---|
| Type | Silent Type | Cooling System Type | Air Cooling System |
| Rated Current | 12V/8.3A | Speed | 3000rpm/3600rpm |
| Starting System | 12V DC Electric Start | Place of Origin | Jiangsu, China |
| Model Number | SED7500SEW | Brand Name | SealinePower or OEM |
| Weight | 160KG | Product Name | Silent Diesel Generator |
| Warranty | 1 Year or 500 Hours | Engine | Chinese Engine |
| Generator Type | Silence Generator Set | Package | Carton Packaged |
| Phase | 1 Phase/3 Phase | Certification | CE, ISO9001 |
| Selling Units | Single item |
Products Description
|
Model
|
SED7500S
|
||
|
GENERATOR
|
Frequency (HZ)
|
50/60HZ
|
|
|
Max Output (KV)
|
5.5/6.0
|
||
|
Rated Output(KV)
|
5.0/5.5
|
||
|
Rated AC Voltage(V)
|
120, 220, 230, 240, 380, 400,120/240,220/380 etc.
|
||
|
Power Factor
|
1
|
||
|
DC Output (V)
|
12V/8.3A
|
||
|
Phase
|
Single Phase
|
||
|
Alternator Type
|
Self-excited, 2-pole, Single Alternator
|
||
|
Starting System
|
Electric
|
||
|
Noise Level (Dba/7m)
|
68-72 Db
|
||
|
Fuel Tank Capacity (L)
|
16
|
||
|
Continuous Running Time (hr)
|
8.5
|
||
|
ENGINE
|
Engine Model
|
SE188FE
|
|
|
Engine Type
|
Single-cylinder, Vertical, 4-stroke, Air-cooled diesel engine
|
||
|
Bore×Stroke (mm)
|
88×75
|
||
|
Fuel Consumption rate (g/kw/h)
|
≤280
|
||
|
Fuel
|
0# or -10# light diesel oil
|
||
|
Lubrication Oil Volume (L)
|
1.65
|
||
|
Combustion System
|
Direct Injection
|
||
|
STANDARD FEATURES
|
Voltmeter
|
YES
|
|
|
AC Output Socket
|
2
|
||
|
AC Circuit Breaker
|
YES
|
||
|
Oil Warning Light
|
YES
|
||
|
Oil Alert
|
YES
|
||
|
OPTIONAL FEATURES
|
Dccircuit Breaker
|
OPTIONAL
|
|
|
Calculagraph
|
OPTIONAL
|
||
|
Big Wheel
|
OPTIONAL
|
||
|
Three Phase Voltage
|
OPTIONAL
|
||
|
Current Meter
|
OPTIONAL
|
||
|
ATS
|
OPTIONAL
|
||
|
Remote Control
|
OPTIONAL
|
||
|
DIMENSIONS
|
Dimention(LxWxH)(mm)
|
915*530*685
|
|
|
Net Weight(kgs)
|
165
|
||
|
20FT Loading Pcs
|
91
|
||
