Diesel Generator Set | ||
Generator Set | Brand | Sealine |
Prime Power(KVA) | 200 | |
Standby Power(KVA) | 220 | |
Rated Frequency(Hz) | 50/60 | |
Rated AC Voltage(V) | 220/380, 240/400 | |
Starting System | Electric Starter | |
Noise Level(Dba/7m) | 70-72 | |
Continuous Running Time(Hr) | 8-12 hours fuel tank | |
Diesel Engine | Brand | DCEC Cummins |
Model | 6CTAA8.3-G2 | |
Number of Cylinders | 4 | |
Rotating Speed(rpm) | 1500 | |
Cylinder Arrangement | 4 in line | |
Cycle | Four stoke | |
Aspiration | Turbocgarged air-air cooled | |
Bore×Stroke(mm) | 114×135 | |
Displacement(L) | 8.3 | |
Compression Ratio | 16:1 | |
Engine Oil Tank Capacity(L) | 18.9 | |
Speed Governor | Electrical | |
Cooling System | Water-cooled | |
Speed Stability (%) | ≤5% | |
Total Lubrication System Capacity (L) | 24 | |
Coolant Capacity (Inc. Radiator) (L) | 40 | |
Fuel Consumption at 100% Load | 209.0L/hr(at 1500RPM) | |
Starting Method | DC24V Electrical starting | |
Alternator | Brand | Stamford / Leroy Somer / other |
Number of Phase | 3 | |
Power Factor(cosθ) | 0.8(lagging) | |
Connecting Type | Three Phase and Four Lines | |
Number of Bearing | 1 | |
Grading Protection | IP23 | |
Altitude | ≤1000m | |
Exciter Type | Brushless, self-exciting | |
Insulation Class | H degree | |
Dimension & Packing | Dimension(L*W*H)(mm) | 3590×1250×2050 |
Net Weight(kg) | 2750 | |
Packing | In Strong Corrugated Board Carton | |
20FT Loading Quantity | 3 | |
Payment | Payment Terms | T/T or L/C |
Minimum Order Quantity | 1 unit | |
Delivery Lead Time | Within 15days after received the depsoite | |
Warranty | One Year or 1000 Working Hours |
